The right angle J1939 1 male to 2 female J1939 splitter Y cable is a cable used for vehicle communication systems. The following is a specific introduction:

Structural characteristics

Interface form: One end is a right angled J1939 male connector, which facilitates the connection of female connectors with other devices in a right angled manner, saving space and adapting to the compact wiring environment inside the vehicle. In addition, the two ends are J1939 female connectors, which can be connected to two devices or systems with J1939 male connectors respectively.

Cable structure: Similar to regular J1939 cables, the internal conductor is usually made of high-quality copper material to ensure good conductivity; The insulation layer is made of polyvinyl chloride (PVC) or cross-linked polyethylene (XLPE) to ensure insulation and mechanical properties; There may be shielding layers, such as copper wire woven mesh or aluminum foil, used to resist electromagnetic interference.

performance parameter

Electrical performance: The working voltage is generally 12V or 24V commonly used in vehicles, which can adapt to the power environment of the vehicle's electrical system. The data transmission rate can meet the requirements of J1939 protocol, usually reaching 250Kbps or higher, ensuring fast and accurate data communication between various control systems of the vehicle.

Mechanical performance: It has good flexibility and bending resistance, and can flexibly bend when wiring inside the vehicle, adapting to different installation positions and paths. Capable of withstanding certain tensile and compressive forces, maintaining stable connections under vibrations and impacts during vehicle operation, and avoiding issues such as looseness or breakage.
